5 Channel – 5 x 3A – CASAMBI & RF – RGB/W – CCT – Single Colour – APP – LED Receiver
Commercial Grade LED Controller
Full Specification
| Product Code | RC-CASAMBI-RGB-5 |
| Protocol | CASAMBI / RF |
| Compatible LED | – White & Single Colour – Colour Changing (RGB/W) – Tunable White (CCT) |
| Product Type | Receiver |
| Zones (channels) | 1 |
| Input Voltage | 12-24V DC |
| Input Current | 15.5A |
| Output Voltage | 12-24V DC |
| Output Current | 5 x 3A/CH (15.5A) |
| Output Wattage | 180W -12v / 360W – 24v |
| Signal | CASAMBI |
| Dimming Range | 0 -100% |
| Dimensions | L120 x W43 x H35mm |
| Weight | 0.073kg |
| Warranty | 5 Years |
| EMC standard (EMC) | EN IEC 55015/EN IEC 61547 ETSI EN 301 489-1/-3/-17 |
| Safety standard(LVD) | EN 61347-1/-2 |
| Radio Equipment(RED) | ETSI EN 300 440 ETSI EN 300 328 |
| Certification | CE, RoHs |
| Compatible Products | CT-CCT-4-B / CT-CCT-4-W / CT-DIM-4-B / CT-DIM-4-W / CT-RGBW-4-W / CT-RGBW-4-B CT-WALL-1-DIM-BAT / CT-WALL-4-CCT-BAT / CT-WALL-4-DIM-BAT / CT-WALL-4-RGBW-BAT RM-CCT-1 / RM-CCT-8 / RM-DIM-1 / RM-DIM-8 / RM-RGBW-1 / RM-RGBW-8 |
5 Channel Casambi & RF LED Receiver – RGBW, CCT & Single Colour (App Controlled)
Take complete control of your commercial lighting with this 5 Channel Casambi & RF LED Receiver. Designed for professional installations, it supports single colour, tunable white (CCT), RGB and RGBW LED lighting, making it a versatile solution for offices, retail spaces, hospitality venues and architectural projects.
Compatible with the Casambi platform, the receiver allows intuitive wireless control through the Casambi app, while also supporting compatible RF wall controllers and remote controls. Smooth 0–100% dimming provides precise adjustment of brightness, colour temperature and colour output to create the perfect lighting scene.
Operating on 12–24V DC, it delivers up to 3A per channel with a maximum output of 360W at 24V. Its compact housing allows for discreet installation, while CE and RoHS certification and compliance with recognised EMC, LVD and RED standards ensure dependable performance.
Backed by a comprehensive 5-year warranty, this receiver offers reliable, flexible control for demanding commercial LED lighting systems.
